LYNX  - FireBall 280 - Tail Pitch Slider, Red

 Download PDF Manual here


Lynx Heli Innovations offer now a new Fireball tail pitch slider edition, using double bearing support and full metal construction, assure the best tail precision and fly performance.
Lynx Fireball tail pitch slider assure the best travel and tail authority.
Special design and assembly features assure precise tail pitch slider move, without play or friction for the ultimate tail performance.
The details and design of this tail pitch slider add top performance in your Fireball tail system.
We spent hours optimizing the design to achieve the required strength with a final weight beyond compromise. We are pilots, we expect from our upgrade a better performance.

FEATURES:
- Double bearing support – ultimate play free functions.
- Direct replacement for the standard Fireball tail parts.
- Increase tail response and reduce vibration.
- Preassembled with lock thread and greased bearing.
- Pitch Slider Ring in SST and Slider Bushing in Brass 360 for the ultimate free-friction and smooth pitch travel operation.
- Designed and tested with very high head speed
- FEA (Finite Elements Analysis) design assisted, achieve lightweight and maximum strength.

TECHNICAL SPECIFICATION:
- Pitch Slider Ring Material: SST
- Slider Bushing Material: Brass 360
- Pitch Slider Half Moon: Aluminum 7075-T6 – Anodized
- All Pivot Bushing Material: Brass 360
- Bearing Material: Chrome Steel – ABEC5 – Japan Brand
- Hardware Material: Carbon Steel – Class 12.9
- Weight: 1.7g

PACKING LIST:
1 x Fireball – Tail Pitch Slider - Red - Preassembly
