Tarot 250/SE Torque Tube Modify Kit

Product Description:
For modify 250 belt version to Torque Tube tail drive version

Product Specification:
CNC Metal TT front drive gear mount(14.05x16.50x11.65mm)
Bearing * 2pcs (Φ2xΦ5x2.5mm) (Front mount & gear box)
Bearing * 2pcs (Φ3xΦ6x2.5mm) (Front mount & gear box)
T5 button head Torx screws * 4pcs (0#x1mm 80T)
250 TT long bevel gear * 1pc (Φ3.0xΦ7.6x5.80mm)
250 TT short bevel gear * 1pc (Φ3.0xΦ7.6x2.85mm)
250 TT front drive shaft * 1pc (Φ2.0xΦ2.5x15.00mm)
250 TT front drive gear * 1pc (Φ2.5xΦ11.8x4.28mm)
TT tail gear box * 1pc (10.8x5mm)
TT bevel gear * 1pc
Spindle bevel gear * 1pc
Tail rotor spindle * 1pc (Φ2x29mm)
Crossmember for tail gear box side plate *1pc (Φ1.5xΦ2.9x10.80mm)
Carbon fiber tail drive shaft rod * 1pc (Φ2.5x253mm)
Stainless steel TT connector * 2pcs (Φ2xΦ2.8x10.05mm)
TT matel holder * 1pc (Φ4.0xΦ6.9x6.0mm)
TT holder bearing washer * 1pc (Φ4.0xΦ5.0x1.9mm)
TT holder bearings * 2pcs (Φ2.5xΦ5.0x1.3mm)
TT holder O ring * 2pcs (Φ4.5xΦ7.7x1.6mm)
Instruction Manual * 1 (http://i1094.photobucket.com/albums/i447/bennyhawkrc/250TTmanual.jpg)
