Features

1. New Formula version X5, stylish Black/Red anodized CNC parts.
2. New Low CG FORMULA FBL rotor head, Formula Rotor Head is 10mm lower than the
previous standard X5 Rotor head. Increase in flight characteristics of X5.
3. CNC Washout Arm centered on Main Rotor head allowed more precise 3D flight control by pilots.
4. Main blade grip adopts pilot selectable 3 holes design, making it easy to adjust for various flight control reaction to fit each pilot.
5. X Series laser logo with dual color artistic design.
6. 3K CF frame has anti-erosion, anti-thermal expansion, tensile characteristics.
7. Advanced new CNC Swash plate with light weight design.
8. Swash plate gap adjustment and anti-shedding steering linkage ball design.

Content:

♦X5 FORMULA Basic Kit x 1 set

♦Tail Rotor Blade Set(82mm) x 1 set

Specifications:

Height: 315mm,
Width: 165mm,
Length (including canopy): 1000mm
Weight: 1820g +/-3% (including electronics without battery)
Main Blades: 500 ~ 530mm,
Main blade rotation diameter 1120mm
Tail blade: 82mm,
Tail rotation diameter: 230mm
Power System recommendation: Motor: 910kV,
ESC: 100A Flight time: 4~5minutes

Required for operation

*Transmitter(6-channel or more,helicopter system)
*Receiver(6-channel or more)
*LiPo Battery: 6S1P(22.2v/4200mah / size:48x44x135mm)
*ESC: 100A+ ESC recommended

Tools and Equipment for Assembly

*1.5 mm Hexagon Screw Driver
*2 mm Hexagon Screw Driver
*2.5 mm Hexagon Screw Driver
* Philips Screw Driver
* Lubricant / one-way bearing grease
* Spring calipers, Needle-nosed pliers
* General thread lock
