HobbyWing Platinum PRO V4 120A ESC (3S-6S)

Model Platinum 120A V4 ESC
Application 500- 550 Class Helicopter
Input Voltage 3-6S Lipo
Cont./Peak Current (10s) 120A/150A
(Switch-mode) BEC 5V-8V Adjustable (Step: 0.1V), 10A/25A Cont./Peak
Separate Programming Port For connecting LCD Program Box/WIFI Express
Throttle Signal/BEC Output/RPM Signal Transmission Wire(s) White Throttle Signal Wire/Red & Black and Red&Brown BEC Output Wires/Yellow RPM Signal Transmission Wire
Input Wires Red-12AWG-150mm*1/Black-12AWG-150mm*
Output Wires Black-12AWG-100mm*3
Output connector 4.0mm Gold Connectors (Female)
Size 84.3x38.2x20.4mm
Weight 107g / 3.77oz
