Mini Protos - Ultra Dampeners - V2

Instruction Manual
--> Download PDF Manual here


Lynx Heli Innovation listen pilots experience redesign the well know Mini Protos Ultra Dampeners and he made it better, perfect for the extreme 3D performance you are looking for.
New design has one single o-ring and the bushing is made with different fitting tolerance.
We also add in the package 6 x shims for the perfect adjustment in your Heli.
Those shims need add between the Main Grip Bearing and the Standard Mini Protos Spacer If need to get the perfect lock without binding or play.

Here at Lynx Heli Innovations we are helicopter pilots and fly the same models you do.
From our test experience we decided to design special Mini Protos dampeners and made it suitable for intense 3D maneuvers.
By combining our engineering and helicopter experience we have designed special dampeners that hold the spindle and reduce play to emphasize the quick cyclic input reaction.
Our dampeners will increase the response and the fly precision in your Mini Protos and are designed to work in FB as FBL Head.
Lynx Mini Protos dampeners are composed by tree pieces - two O-ring to maintain the necessary preload (to remove any play) and one bushing in techno-polymer auto-lube to assure maximum load and friction resistance.
These dampeners give your Mini Protos an incredibly precise feel in the air. The difference is visible, particularly in fast forward flight and with quick pitch changes, or any complex 3D maneuvers.
Our tests show that Mini Protos Lynx dampeners are advised when high head speed is requested, specially designed for 3D fly.
FEATURES:
-         Increased head rigidity give precise and crispy fly feeling with standard plastic head or with any brand head upgrades parts.
-         Quick move response
-         Incredible spam life resistance.
-        Direct replacement for your Mini Protos Heli FB or FBL Head.
TECHNICAL SPECIFICATION:
-         O-Ring Material:  EPDM Rubber Compound (Elastomer)
-         Bushing Material: Techno-Polymer base POM.
PACKING LIST:
4 x Mini Protos Ultra Dampeners – Bushing
4 x O-Ring Elastomer
6 x Shims for perfect adjustment.

TIPS FOR BEST PERFORMANCE AND EASY INSTALLATION:
Before install Lynx Mini Protos dampeners disassembly the main grip and remove STD dampeners, keep the STD metal shims for final assembly.
Don’t lubricate the O-Ring or any other parts.
1- Install the Bushing with O-Ring respecting the direction shown in the extra picture below. Please note that V2 POM bushing will fit very tight on the center hub, and then don’t be surprised if pressure is needed.
2- Install the standard Mini Protos Metal Shims per normal user manual instruction.
3- Install Main Grip but doesn’t lock thread the spindle screw at this moment.
4- Check the assembly, if any plays present in the spindle, use the supported extra shims to increase o-ring pre-compression and get a perfect solid assembly. Our experience show that perfect pre-compression is when the system have a little rotation friction on the bench test. In fly that friction will disappear leaving a solid assembly without any play.
5- Remind before install Main Blade to lock the spindle screw with lock thread.
Once Heli assemble, test and in case of cyclic shacking adjust cyclic gain reducing Aileron and Elevator gain.
